Detail
| Code | Dash | DN | Hose I.D. | Hose I.D. | Hose O.D. | Hose O.D. | Working Pressure | Working Pressure | Min. Burst Pressure | Min. Burst Pressure | Min. Bend Radius | Min. Bend Radius | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (psi) | (Bar) | (psi) | (Bar) | (mm) | (in) | |||||
| H323020 | 20 | 32 | 1.1/4 | 31.8 | 1.98 | 50.2 | 3045 | 210 | 12180 | 840 | 460 | 18.10 | 1.81 | 46.0 |
| Dash | DN | Hose I.D | Hose I.D | Hose O.D | Hose O.D | Working Pressure | Working Pressure | Min. Burst Pressure | Min. Burst Pressure | Min. Bend Radius | Min. Bend Radius | Reinforcement O.D | Reinforcement O.D |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| -24 | 38 | 1.1/2 | 38.1 | 2.23 | 56.6 | 2680 | 185 | 10730 | 740 | 560 | 22.05 | 2.06 | 52.4 |
SDA Item No.
