APPLICATION
Medium pressure hydraulic lines 40 to 250 bar and requires compact outer dia. For use with petroleum, synthetic or water based fluids in hydraulic systems. Suitable for agricultural, earthmoving & material handling equipments and machineries/systems.
CONSTRUCTION
Core: Oil & water resistant Synthetic rubber
Reinforcement: Single steel wire braid
Cover: Black Color, Synthetic rubber resistant to weather and abrasion, oil & ozone.
TEMPERATURE RANGE
Continuous: -40°C to +120°C
Medium pressure hydraulic lines 40 to 250 bar and requires compact outer dia. For use with petroleum, synthetic or water based fluids in hydraulic systems. Suitable for agricultural, earthmoving & material handling equipments and machineries/systems.
CONSTRUCTION
Core: Oil & water resistant Synthetic rubber
Reinforcement: Single steel wire braid
Cover: Black Color, Synthetic rubber resistant to weather and abrasion, oil & ozone.
TEMPERATURE RANGE
Continuous: -40°C to +120°C
| Part Number | Dash | I.D | O.D | Weight | W.P | Bend Radius |
|---|---|---|---|---|---|---|
| (mm) | (mm) | (kg/m) | (psi) | (mm) | ||
| E4KAA02000 (4WS) | -12 | 19.0 | 29.0 | 0.978 | 4000 | 120 |
| E4KAA02500 (4WS) | -16 | 25.0 | 37.2 | 1.479 | 4000 | 150 |
| E4KAA03200 (4WS) | -20 | 32.0 | 44.2 | 2.214 | 4000 | 210 |
| E4KAA03800 (4WS) | -24 | 38.0 | 50.6 | 2.610 | 4200 | 250 |
| E4KAA05100 (4WS) | -32 | 51.0 | 64.7 | 4.001 | 4000 | 318 |
