| Code | Dash | DN | Hose I.D. | Hose I.D. | Hose O.D. | Hose O.D. | Working Pressure | Working Pressure | Min. Burst Pressure | Min. Burst Pressure | Min. Bend Radius | Min. Bend Radius |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (psi) | (Bar) | (psi) | (Bar) | (mm) | (in) | |||
| H323004 | 4 | 6 | 1/4 | 6.4 | 0.69 | 17.6 | 6525 | 450 | 26100 | 1800 | 5.90 | 150 |
| H323006 | 6 | 10 | 3/8 | 9.5 | 0.83 | 21.1 | 6450 | 445 | 25810 | 1780 | 180 | 7.10 |
| H323008 | 8 | 12 | 1/2 | 12.7 | 0.96 | 24.3 | 6015 | 415 | 24070 | 1660 | 230 | 9.05 |
| H323010 | 10 | 16 | 5/8 | 16.0 | 1.10 | 27.9 | 5075 | 350 | 20300 | 1400 | 250 | 9.85 |
| H323012 | 12 | 19 | 3/4 | 19.0 | 1.26 | 31.9 | 5075 | 350 | 20300 | 1400 | 300 | 11.80 |
| H323016 | 16 | 25 | 1 | 25.4 | 1.54 | 39.2 | 4060 | 280 | 16240 | 1120 | 340 | 13.40 |
| H323020 | 20 | 31 | 1.1/4 | 31.8 | 1.98 | 50.2 | 3045 | 210 | 12180 | 840 | 460 | 18.10 |
| H323024 | 24 | 38 | 1.1/2 | 38.1 | 2.23 | 56.6 | 2680 | 185 | 10700 | 740 | 560 | 22.05 |
| H323032 | 32 | 51 | 2 | 50.8 | 2.72 | 69.2 | 2395 | 165 | 10000 | 690 | 660 | 26.00 |
