APPLICATION
Medium pressure hydraulic lines 40 to 250 bar and requires compact outer dia. For use with petroleum, synthetic or water based fluids in hydraulic systems. Suitable for agricultural, earthmoving & material handling equipments and machineries/systems.
CONSTRUCTION
Core: Oil & water resistant Synthetic rubber
Reinforcement: Single steel wire braid
Cover: Black Color, Synthetic rubber resistant to weather and abrasion, oil & ozone.
TEMPERATURE RANGE
Continuous: -40°C to +120°C
Medium pressure hydraulic lines 40 to 250 bar and requires compact outer dia. For use with petroleum, synthetic or water based fluids in hydraulic systems. Suitable for agricultural, earthmoving & material handling equipments and machineries/systems.
CONSTRUCTION
Core: Oil & water resistant Synthetic rubber
Reinforcement: Single steel wire braid
Cover: Black Color, Synthetic rubber resistant to weather and abrasion, oil & ozone.
TEMPERATURE RANGE
Continuous: -40°C to +120°C
| Part Number | Dash | I.D | O.D | Weight | W.P | Bend Radius |
|---|---|---|---|---|---|---|
| (mm) | (mm) | (kg/m) | (psi) | (mm) | ||
| 8Z7AA00600 | -4 | 6.0 | 14.5 | 0.330 | 5850 | 100 |
| 8Z7AA00800 | -5 | 8.0 | 16.1 | 0.357 | 5000 | 115 |
| 8Z7AA01000 | -6 | 10.0 | 18.5 | 0.463 | 4800 | 125 |
| 8Z7AA01200 | -8 | 13.0 | 21.4 | 0.534 | 4000 | 175 |
| 8Z7AA01600 | -10 | 16.0 | 24.6 | 0.665 | 3630 | 200 |
| 8Z7AA02000 | -12 | 19.0 | 29.0 | 0.895 | 3120 | 240 |
| 8Z7AA02500 | -16 | 25.0 | 36.8 | 1.253 | 2400 | 300 |
| 8Z7AA03200 | -20 | 32.0 | 46.4 | 1.852 | 1820 | 420 |
| 8Z7AA03800 | -24 | 38.0 | 52.8 | 2.086 | 1310 | 500 |
| 8Z7AA05100 | -32 | 51.0 | 65.6 | 2.748 | 1200 | 630 |
