APPLICATION
Medium pressure hydraulic lines 40 to 250 bar and requires compact outer dia. For use with petroleum, synthetic or water based fluids in hydraulic systems. Suitable for agricultural, earthmoving & material handling equipments and machineries/systems.
CONSTRUCTION
Core: Oil & water resistant Synthetic rubber
Reinforcement: Single steel wire braid
Cover: Black Color, Synthetic rubber resistant to weather and abrasion, oil & ozone.
TEMPERATURE RANGE
Continuous: -40°C to +120°C
Medium pressure hydraulic lines 40 to 250 bar and requires compact outer dia. For use with petroleum, synthetic or water based fluids in hydraulic systems. Suitable for agricultural, earthmoving & material handling equipments and machineries/systems.
CONSTRUCTION
Core: Oil & water resistant Synthetic rubber
Reinforcement: Single steel wire braid
Cover: Black Color, Synthetic rubber resistant to weather and abrasion, oil & ozone.
TEMPERATURE RANGE
Continuous: -40°C to +120°C
| Part Number | Dash | I.D | O.D | Weight | W.P | Bend Radius |
|---|---|---|---|---|---|---|
| (mm) | (mm) | (kg/m) | (psi) | (mm) | ||
| E5PAA02000 | -12 | 19.0 | 30.2 | 1.276 | 5500 | 120 |
| E5PAA02500 | -16 | 25.0 | 37.4 | 1.817 | 5500 | 150 |
