APPLICATION
Medium pressure hydraulic lines 40 to 250 bar and requires compact outer dia. For use with petroleum, synthetic or water based fluids in hydraulic systems. Suitable for agricultural, earthmoving & material handling equipments and machineries/systems.
CONSTRUCTION
Core: Oil & water resistant Synthetic rubber
Reinforcement: Single steel wire braid
Cover: Black Color, Synthetic rubber resistant to weather and abrasion, oil & ozone.
TEMPERATURE RANGE
Continuous: -40°C to +120°C
Medium pressure hydraulic lines 40 to 250 bar and requires compact outer dia. For use with petroleum, synthetic or water based fluids in hydraulic systems. Suitable for agricultural, earthmoving & material handling equipments and machineries/systems.
CONSTRUCTION
Core: Oil & water resistant Synthetic rubber
Reinforcement: Single steel wire braid
Cover: Black Color, Synthetic rubber resistant to weather and abrasion, oil & ozone.
TEMPERATURE RANGE
Continuous: -40°C to +120°C
| Part Number | Dash | I.D | O.D | Weight | W.P | Bend Radius |
|---|---|---|---|---|---|---|
| (mm) | (mm) | (kg/m) | (psi) | (mm) | ||
| E6KAA00600 (4WS) | -4 | 6.0 | 17.0 | 0.510 | 6550 | 60 |
| E6KAA01000 (4WS) | -6 | 10.0 | 19.8 | 0.615 | 6450 | 75 |
| E6KAA01200 (4WS) | -8 | 13.0 | 22.5 | 0.710 | 6000 | 90 |
| E6KAA01600 (4WS) | -10 | 16.0 | 27.8 | 1.190 | 6000 | 100 |
| E6KAA02000 (4WS) | -12 | 19.0 | 30.6 | 1.371 | 6000 | 120 |
| E6KAA02500 (4WS) | -16 | 25.0 | 38.0 | 1.926 | 6000 | 150 |
| E6KAA03200 (6WS) | -20 | 32.0 | 47.6 | 2.982 | 6000 | 225 |
| E6KAA03800 (6WS) | -24 | 38.0 | 54.4 | 4.155 | 6000 | 305 |
| E6KAA05100 (6WS) | -32 | 51.0 | 68.7 | 6.074 | 6000 | 380 |
